Description
Dimensions and Weight
- Height: 125 mm
- Width: 125 mm
- Depth: 54.2 mm (bracket included)
- 24.5 mm (bracket not included)
- Note: The size may vary depending on configuration, manufacturing process, or measurement.
- Weight: About 155 g (excluding the power adapter)
Note: The actual weight may vary depending on configuration, manufacturing process, or measurement.
5G/4G
- 4G Transmission Rate
- Max.DL: 195 Mbps
- Max.UL: 105 Mbps
Note: Theoretical value. The actual rate varies with the operator, network conditions, distance, and terminal type.
Wi-Fi
- Transmission Standard: Wi-Fi 4
- Wireless Transmission Rate: 2.4 GHz: 300 Mbps (theoretical valueοΌ
- Wireless Frequency Band: 2.4 GHz
Antenna
- 5G/4G Antenna Type: Built-in 4G main and diversity antennas, external antennas can be removable
- WLAN Antenna Type: Built-in 2.4G Wi-Fi antenna, non-removable
Memory
- RAM: 128 MB
- ROM: 128 MB
Interface
- External antenna ports (SMA): 1
- 100 Mbps LAN/WAN port (RJ45): 1
- Power port: 1
- Nano-SIM card slot: 1
Button
- WPS button: 1
- Reset button: 1
LED Indicator
- Internet status indicator: 1
- Wi-Fi indicator: 1
- Signal strength indicators: 3
Power Supply
- Power: < 12 W
- AC / DC Power Supply: AC: 100Vο½240V DC: 12V/1A
Software Functions
HUAWEI AI Life App
Security
Anti-brute Force Cracking: Supported
Firewall: Supported
DoS Attack Protection: Supported
Wi-Fi Encryption Authentication: Supported WPA-PSK/WPA2-PSK/WPA3-SAE
Environment
- Temperature
- Operating Temperature: 0Β°C ~ 40Β°C
- Storage Temperature: -20Β°C ~ +70Β°C
Packing List
- CPE: 1 (Standard)
- Quick start guide: 1 (Standard)
- Power adapter: 1 (Standard)
