DJI Osmo 360 II Standard

General

• Dimensions
  • Length 61 mm, width 36.3 mm, height 81 mm
• Weight
  • 183g
• Waterproof
  • Bare 10 m, waterproof shell 50 m
    • The data came from the DJI laboratory and were measured in specific controlled water pressure environments. The data is for reference only, the actual use of the specific diving environment and the actual status of the product is subject to. Before use, close the battery compartment cover and USB-C interface cover. The Osmo 360 II passed the standard IP68 waterproof test for GB/T 4208-2017 and IEC 60529-2013 housing protection. This product is not recommended in extreme water environment and unknown liquid environment, and should not be used in hot springs and corrosive liquids. The camera supports bare metal 10 meters waterproof, but because the fish eye convex mirror may be used underwater due to optical refraction caused by image distortion and panoramic splicing errors, it is recommended to avoid direct bare metal underwater shooting. The Osmo 360 fully invisible waterproof case is available separately. With the Osmo 360 fully invisible waterproof case used underwater, the safe splicing distance is 1 meter.
• Microphone
  • 4 (including 1 windproof microphone)
• Touch screen
  • Dimensions: 2.0 inches
  • Resolution: 314 × 556
  • Brightness: 800 nits
• Installation method
  • Bidirectional magnetic suction fast disassembly design
• Mimo Connection
  • NFC Quick Connection
• Camera
  • Replaceable outer lens design
• Support for memory card types
  • MicroSD card (maximum 1 TB support)

Camera

• Image sensor
  • Double 1/1.1 inch square CMOS
• Aperture
  • f/1.9
• ISO Scope
  • 100 to 51200
• Electronic shutter speed
  • Photo: 1/8000th to 30 seconds
  • Video: 1/8000th of a second to frame rate limit shutter
• Maximum resolution of photos
  • Panorama photo:
  • 2:1,15520 × 7760 (120 million pixels)
  • Single-lens photo:
  • 4:3,6400 × 4800 (30.72 megapixels)
  • Support for HDR photos
• Panorama video
  • 8K: 7680 × 3840@24/25/30/48/50/60fps
  • 6K: 6000 × 3000@24/25/30/48/50/60fps
• Panoramic view – Super Night View
  • 8K: 7680 × 3840@24/25/30/48/50/60fps
  • 6K: 6000 × 3000@24/25/30/48/50/60fps
• Panorama – Selfie Mode
  • 4K: 3840 × 3840@25/30/50/60fps
  • 3K: 3000 × 3000 @ 25/30/50/60fps
• Panorama – The protagonist follows
  • 4K@24/25/30fps
  • 2.7K @ 24/25/30fps
• Panorama – slow motion
  • 4K: 3840 × 1920@100/200/240fps
• Panorama – Time-lapse photography
  • Movement delay
    8K@25/30fps: Auto/× 2/×5/×10/×15/×30
    Standstill delay
    16K @ 25/30fps
    8K @ 25/30fps
    Shooting mode: Clouds comfortably (10 minutes/2 seconds)/Sunrise and sunset (1 hour/3 seconds)/Customization
    Custom shooting interval: 2/3/4/5/6/8/10/15/20/25/30/40 seconds, 1/2/5/30/60 minutes
    Duration: 5/10/20/30 minutes, 1/2/3-5 hours, ∞
• Panorama – Time-time solidification
  • 8K: 7680 × 3840@100/120fps
  • 6K: 6000 × 1500@180/200fps
• Single-camera – video
  • 4K (4:3): 3840 × 2880@25/30/50/60fps
  • 4K (16:9): 3840 × 2160@25/30/50/60fps
  • 2.7K (4:3): 2688 × 2016 @ 25/30/50/60fps
  • 2.7K (16:9): 2688 × 1512@25/30/50/60fps
• Single-lens-Super Night View
  • 4K (4:3): 3840 × 2880@25/30fps Extreme wide angle
  • 4K (16:9): 3840 × 2160@25/30fps Extreme wide angle
  • 2.7K (4:3): 2688 × 2016 @ 25/30fps Extreme wide angle
  • 2.7K (16:9): 2688 × 1512@25/30fps Extreme wide angle
• Single-camera – Extremely wide-angle video
  • 4K (1:1): 3840 × 3840@25/30/50/60fps
  • 4K (4:3): 3840 × 2880@25/30/50/60/100/120fps
  • 4K (16:9): 3840 × 2160@25/30/50/60/100/120fps
  • 4K(9:16): 2160 × 3840@25/30/50/60/100/120fps
  • 2.7K (1:1): 2688 × 2688 @ 25/30/50/60fps
  • 2.7K (4:3): 2688 × 2016@25/30/50/60/100/120fps
  • 2.7K (16:9): 2688 × 1512@25/30/50/60/100/120fps
  • 2.7K(9:16):1512 × 2688@25/30/50/60/100/120fps
• Stabilized
  • Electronic stability:
  • RockSteady 3.0
  • The Horizon Steady
    • In panoramic video mode, you can choose to stabilize mode when exporting the DJI Mimo app or DJI Studio. HorizonSteady Horizon Stabilization in single-lens mode supports only a 16:9-ratio standard (rataneous correction) view of ordinary flat-panel video (≤ 60fps); in single-lens extreme wide-angle mode, Horizon Steady Horizon booster only supports 60fps and below flat-panel video.
• Pre-recorded
  • Pre-recording time: 5/10/15/30 seconds, 1/2/5 minutes
• Video storage maximum stream
  • 220Mbps (16K panoramic still delay video: 600Mbps)
• Support for file systems
  • exFAT
• Image format
  • JPEG and RAW
• Video format
  • OSV/MP4 (HEVC)
• Built-in storage capacity
  • Built-in storage 128GB (use available: 105GB) with microSD card slot expansion
• Audio recording
  • 48 kHz 16-bit; AAC
• Safe splicing distance
  • ≥ 75 cm
  • With the Osmo 360 fully invisible waterproof case used underwater, the safe splicing distance is 1 meter.

Battery

• Type
  Li-ion 1S
• Capacity
  2150 mAh
• Use of ambient temperature
  -20°C to 45°C
• Charging ambient temperature
  5°C to 40°C
• Working hours
• Up to 100 minutes of recording 8K/30fps panoramic video
• In laboratory conditions at 25 °C, turn off Wi-Fi, gesture control, voice control, quick-cut assistant, record panoramic 8K/30fps video and turn off the screen. The data comes from the DJI laboratory and is for reference only. When the Osmo 360 II is activated and used in the EU and the UK, the battery life is different from the data shown on this page due to the local regulations on the operating temperature of the product, please refer to the actual experience.

Connect

• Wi-Fi operating frequency
  2.400 GHz to 2.4835 GHz
  5.150 GHz to 5.250 GHz
  5.725 GHz to 5.850 GHz
• Wi – Fi Protocol
  Wi-Fi 6
  802.11 a/b/g/n/ac/ax
• Wi – Fi Protocol
  Wi-Fi 6
  802.11 a/b/g/n/ac/ax
  Wi-Fi 6
  802.11 a/b/g/n/ac/ax
  Wi-Fi Transmission Power (EIRP)
  2.4 GHz: < 20 dBm (CE/SRRC/MIC)
  5.1 GHz: < 23 dBm (CE/SRRC/MIC)
  5.8 GHz: < 23 dBm (SRRC), < 14 dBm (CE)
• Bluetooth operating frequency
  2.400 GHz to 2.4835 GHz
• Bluetooth Transmission Power (EIRP)
  < 13 dBm
• Bluetooth protocol
  BLE 5.4, BR/EDR
